JUNXY 230V 6KW 6U Intelligent Load Banks For Data Center Heat Load Test

×

It is really critical that your standby power system say UPS(uninterrupted power supply), battery bank, generator, transformers, inverter etc working in good condition if switched to be loaded when the main power supply in maintenance procedure or stop abnormally. Downtime could be reduced by regular maintenance and thorough inspections which are the key to power supply systems maintenance. Critical power backup equipment like UPS System and generator which especially located in harsh, dusty or corrosive environment will fail without proper preventative maintenance. So validating the condition and output of such power systems must be conducted comprehensively. JUNXY provides a whole range of custom preventative maintenance products solutions for UPS systems and generators and many more to ensure constant uptime for your power systems and make you prepared for anything.

Following on from construction and testing, Data Centre Commissioning is essential to ensure that the completed facility is configured for maximum efficiency. Missing out the essential Data Centre Commissioning can lead to an inefficient facility and higher than expected operational costs. By simply identifying where equipment manufacturers’ standard specifications are not appropriate for the IT load, the supporting infrastructure, in particular the cooling plant, can be configured to meet the requirements of the facility and lead to much higher levels of efficiency. Data centre commissioning can lead to significant energy savings when implemented correctly by a specialist commissioning team. By engaging JUNXY power solutions to ensure that systems are running correctly, clients have saved up to 67% on facility operational costs.

The Junxy rack mounted AC & DC load banks are designed especially for internet data center (IDC) test and commissioning. Load bank integrated system test (IST) could precisely simulate the data center’s electricity consumption, heat dissipation, air flow, hot & cold aisle testing, thus to ensure the effective operation of power supply & distribution system (generator, UPS, EPS included), air conditioning system, lightning protection and earthing system, monitoring system, data center integrated environments, cabinet IT environment, providing independent verification of integrated system testing. Successful IST(integrated system test) should have installation of server load banks in data center and server room etc, Junxy provides resistive, reactive and capacitive load banks in low or medium voltage to cover the entire scope of your commission and testing requirements.

Applications:
  • Data center & server room cooling system test
  • Data center air flow, hot/cold aisle environment inspection
  • Validating the tire level of data center
  • Validating the reliability of data center power supply & distribution system
  • Testing the main network before connecting user devices (servers, switches, etc.)

Technical Specifications
ModelJUNXY-AC230V-6KW-R Resistive AC Load Bank
Load ElementAlloy resistors
Load VoltageAC230V single phase 50Hz
Load Power6KW@AC230V
Load Steps0.25KW*2, 0.5KW, 1KW, 2KW*2(0.25KW to 6KW adjustable)
Power FactorPF=1
Load Accuracy±5%
Power SupplyFrom test source(PDU)
Two Control ModesLOCAL: Manual control by push buttons

REMOTE: ONE PC software remote control for all 22 set load banks

Could set both individual and group load bank power
Wire Connections3 set load cables of C19 to C20 for loading
Insulation ClassF
Protection LevelIP20(indoor use)
Cooling ModeForce-air cooling and air flow adjustable:

cold air front inlet & hot air back outlet
Work ModeContinuous work
ProtectionOverheating protection
Dimension6U, 19’’ Standard Rack
Ambient Temperature-10℃~+50℃
MobilityFront handles
Humidity≤95%
Altitude≤2500 meters

Pls kindly click HERE to review the 230V 6KW pure resistive load bank operation video from YOUTUBE!
